利用反滲透的獨特原理,生產純凈水。能大量降低水的無機鹽、有機物、細菌等,主要應用于瓶裝純凈水、小區生活用水、遠洋飲用淡水。
典型工藝
原水 石英砂過濾器 活性碳過濾器
軟化器 反滲透裝置 紫外滅菌
臭氧發生器
純凈水箱 灌裝
主要技術參數
出水流量:0.3-100m3/h
工作溫度:3-35℃
PH值范圍:3-10
工作壓力:0.5-1.55Mpa
It uses the unique principle of
anti-infiltration to produce purified water and
can reduce inorganic salt, organisms and
bacteria in water considerably. It is mainly
used for bottled purified water, living water,
residential domestic water and far-ocean fresh
drinking water.
Typical process
Raw water Quartz sand filter Activated carbon
filter
Softening apparatus Anti-infiltration device
Ultraviolet Germicide
Ozonizer
Purified water tank Filling and bottling
Main technical parameters
Output water flow: 0.3-100m3/h
Working temperature: 3-35℃
PH value range: 3-10
Working pressure: 0.5-1.55Mpa |
